| Engine description | John Deere PowerTech™ PWS (B20 Diesel Compatible) |
| Engine displacement | 4.5 L 275 cu in. |
| Rated engine power | 97/68EC: 99 kW 135 engine hp |
| Rated PTO power (hp SAE) | 86 kW 115 PTO hp |
| Transmission type | Standard: John Deere12F/12R PowrReverser™ Transmission: 30 km/h 19 mph Optional: John Deere 24F/12R PowrReverser Transmission 40 km/h 25 mph |
| Hydraulic pump rated output | 36.5 cc pump: 75.7 L/min 20 gpm |
| Rear hitch category (SAE designation) | Standard: Category 2: 2500 kg (5500 lb) standard lift at 610mm behind hitchpoint Optional: Category 2: 3318 kg (7300 lb) heavy duty lift at 610mm behind hitchpoint |
| Description | John Deere PowerTech™ PWS (B20 Diesel Compatible) |
| Engine type | Diesel, in-line, 4-cylinder, wet-sleeve cylinder liners with 4 valves-in-head |
| Engine family | HJDXLO6.8302 |
| Rated speed | 2200 rpm |
| Aspiration | Turbocharge, wastegate Turbocharger with air to air aftercooling and cooled exhaust gas recirculation |
| Emission level | Final Tier 4 |
| After treatment type | DOC/DPF/SCR |
| Displacement | 4.5 L 275 cu in. |
| Rated power | 97/68EC: 99 kW 135 engine hp |
| Rated PTO power (hp SAE) | 86 kW 115 PTO hp |
| Engine peak torque | At 1,600 rpm: 539 Nm 397 lb-ft |
| PTO torque rise | 30 percent |
| Type | Standard: John Deere12F/12R PowrReverser™ Transmission: 30 km/h 19 mph Optional: John Deere 24F/12R PowrReverser Transmission 40 km/h 25 mph |
| Type | Open-center Gear driven |
| Pump rated output | 36.5 cc pump: 75.7 L/min 20 gpm |
| Available flow at a single rear SCV | 75.7 L/min 20 gpm |
| Number of rear selective control valves (SCVs) | Standard: ISO Couplers 2 Optional: ISO Couplers 3 |
| SCV control | Mechanical |
| Hitch category (SAE designation) | Standard: Category 2: 2500 kg (5500 lb) standard lift at 610mm behind hitchpoint Optional: Category 2: 3318 kg (7300 lb) heavy duty lift at 610mm behind hitchpoint |
| Maximum lift capacity behind lift points | Category 2: with heavy duty lift: 3318 kg 7300 lb |
| Sensing type | Optional |
| Drawbar category | Standard: Category 2 Optional: Category 2 heavy duty |
| Maximum vertical load | Standard: Category 2: 1000-1250 kg 2205-2756 lb Optional: Category 2 heavy duty 1200-1900 kg 2645-4189 lb Maximum vertical load dependent on drawbar position |
| Type | Independent Standard: 35mm (1.375 in) 540 rpm/1000 rpm reversible shaft |
| Engine rpm (at rated PTO speeds) | 2085 engine rpm at 540 rpm PTO 2067 engine rpm at 1000 rpm PTO |
| Type | Flange |
| Final drive type | Inboard planetary |
| Rear differential lock | Full-locking mechanical |
| Type | Standard: MFWD |
| Front axle differential lock | 2WD: None MFWD: limited slip |
| Wheel tread range | MFWD: 1516-2016 mm 59.7-79.4 in. |
| Type | Standard: Hydrostatic power |
| Alternator size | 90 amp |
| Battery options | 12 V |
| Total cold cranking amps | 925 CCA |
| Seat | Standard: Mechanical suspension cloth seat Optional: Air suspension |
| Instructional seat | Optional |
| Display | LCD instrument cluster |
| Wheelbase | MFWD: 2450 mm 96.5 in. |
| Approximate shipping weight, Open;Cab | MFWD Cab: 4645 kg 10,240 lb |
| Maximum ballast level | 6464 kg 14250 lb |
| Crankcase oil volume | 15 L 4 U.S. gal. |
| Fuel tank | 168 L 44.4 U.S. gal. |
| Cooling system | Open station: 18.6 L 4.7 U.S. gal. Cab: 19.1 L 5 U.S. gal. |
| Transmission-hydraulic system | 58 L 15.3 U.S. gal. |
| Interval for engine oil change | 500 hours |
| Interval for hydraulic/transmission oil change | 1,000 hours |
| Interval for engine coolant change | 5,000 hours |
| Country of manufacture | Mexico |
| Date collected | 9-Feb-17 |
