| Cutterbar - Type | SCH® Easy Cut with roller guides, spring steep guards, and bolted sections Standard: single knife or dual knife |
| Cut width (length) | 7.6 m 25 ft |
| Reel type | Hydraulic |
| Fingers | Plastic |
| Belt width | V-guided draper belt: 106.7 cm 42 in. |
| Transport length, hitch extended | 9 m 29.6 ft |
| Type | SCH® Easy Cut with roller guides, spring steep guards, and bolted sections Standard: single knife or dual knife |
| Cut width (length) | 7.6 m 25 ft |
| Knife drive | Two hydraulic motors and two knife drives |
| Knife speed | 1,100 to 1,440 spm |
| Stroke length | 84 mm 3.3 in. |
| Cutterbar tilt | Hydraulic, adjustable from cab |
| Reel type | Hydraulic |
| Number of bats | Six |
| Fingers | Plastic |
| Diameter | 1118 mm 44 in. |
| Height control | Hydraulic, adjustable from cab |
| Speed control | Hydro handle, in cab |
| Reel lift | Hydraulic, adjustable from cab |
| Reel fore and aft | Hydraulic, adjustable from cab |
| Belt width | V-guided draper belt: 106.7 cm 42 in. |
| Delivery opening width | Delivery, double swath opening: 137.2 cm 54 in. Delivery, single swath opening: 203.2 cm 80 in. |
| Delivery opening height | 205.7 cm 81 in. |
| Draper drive | Two hydraulic motors |
| Operating speed | 0 to 232 m/min 0 to 760 fpm |
| Speed control | Adjustable in windrower cab |
| Remote canvas speed control | Standard |
| Deck tilt | Standard |
| Deck extensions | Optional, dealer-installed deck extensions: 35.6 cm 14 in. |
| Type | Optional: factory-installed cross-pea auger |
| Operating width (field) | 7.6 m 25 ft |
| Transport width (reel fully retracted) | 2.6 m 8.5 ft |
| Transport height | 2.44 m 8 ft |
| Transport length, hitch extended | 9 m 29.6 ft |
| Approximate weight (base platform without reel) | 1036 kg 2869 lb |
| Approximate weight (base platform with reel) | 2280 kg 5026 lb |
| Gauge wheels | Adjustable castoring gauge wheel optional |
| Integrated slow speed transport system | Self-contained transport, including hitch, jack and axle, is conveniently stored on the swather table |
