| Number of rows | 48 |
| Row spacing | 38 cm 15 in. |
| Row unit seed hoppers | Capacity Vacuum meter: 2.2 L 0.062 bu |
| Seed Meters | Base Vacuum |
| Number of rows | 48 |
| Row spacing | 38 cm 15 in. |
| Type | Wheel modules with rephasing hydraulic cylinders |
| Base | 445/50R22.5 center frame tires: 517 kPa 5.2 bar (75 psi) 31-13.5x15 six-ply wing frame implement tires: 152 kPa 1.5 bar (22 psi) 31-13.5x16.5 eight-ply wing frame skid steer tires: 241 kPa 2.4 bar (35 psi) |
| Type | MaxEmerge™ 5 row units or MaxEmerge 5e row units or ExactEmerge™ row units |
| Opener | Tru-Vee double disk |
| Row unit seed hoppers | Capacity Vacuum meter: 2.2 L 0.062 bu |
| Base | Vacuum |
| Central Commodity System | 3524 L 100 bu with Refuge Plus option: 4405 L 125 bu |
| Base | Three-motor hydraulic variable-rate drive |
| Type | Automatic alternating or independent control |
| Base | SeedStar™ electronic system |
| Tank capacity | 350 Imperial gal. 1590 L 420 U.S. gal. |
| Transport weight | Average empty weight: 18,416 kg 40,600 lb |
| Recommended tractor horsepower | Requires a minimum 175.2 kW 275 hp Tractor equipped with Category 4 drawbar |
| Recommended tractor hydraulics | Hydraulic oil pump required to operate electric drive planter: 227 L/min 60 gpm Tractor standby pressure: 15,500 kPa 155 bar (2300 psi) Hydraulic system working pressure: 20,684 kPa 207 bar (3000 psi) Hydraulic system burst pressure: 82,737 kPa 827 bar (12,000 psi) |
